Hoshizaki Modular Nugget Ice Machine 730kg/day - FM-1000AKE-N

The Hoshizaki Modular Nugget Ice Machine 730kg/day - FM-1000AKE-N is a powerful and efficient ice-making solution designed to meet the demands of high-volume commercial settings such as large restaurants, stadiums, and cruise ships. With its advanced features, impressive production capacity, and unique nugget ice output, this modular ice machine ensures a reliable and refreshing ice supply to enhance your business operations.

The Hoshizaki FM-1000AKE-N is built to withstand the rigors of commercial use. Its stainless steel construction guarantees durability and resistance to corrosion, making it ideal for demanding environments. The modular design allows for flexible installation options, enabling you to tailor the setup to your specific requirements.

With a remarkable production capacity of 730kg of ice per day, this Hoshizaki ice machine delivers an abundant supply of nugget ice to meet the high demands of your business. The distinctive nugget ice produced by the FM-1000AKE-N offers a chewable texture and excellent liquid displacement, making it perfect for a wide range of applications such as beverages, salad bars, and healthcare facilities.

The Hoshizaki FM-1000AKE-N incorporates advanced technology to optimize ice production and energy efficiency. The CycleSaver® design reduces the duration of the ice-making cycle, resulting in higher efficiency and lower energy consumption. The EverCheck® control system continuously monitors the ice machine's performance, promptly alerting you in case of any issues, ensuring minimal downtime and efficient maintenance.

Hygiene and cleanliness are of utmost importance, and the FM-1000AKE-N simplifies the cleaning process. The stainless steel evaporator and removable parts facilitate quick and effortless cleaning, while the built-in antimicrobial protection inhibits the growth of bacteria, ensuring the safety and quality of your ice.

Elevate your business operations with the Hoshizaki Modular Nugget Ice Machine 730kg/day - FM-1000AKE-N. Its durable construction, high production capacity, and unique nugget ice output make it an exceptional choice for high-volume commercial establishments. Experience the reliability, efficiency, and refreshing ice production that the Hoshizaki FM-1000AKE-N offers, and enhance the overall experience for your customers.

Product Features

• “Freeze Burn” is no longer an issue when displaying fresh fish or produce.
• Carbon auger bearings have a longer life expectancy than roller bearing, reducing maintenance costs.
• Automatic flush function, helps keep the ice making system clean.
• Controller board with Operational Status display assists in troubleshooting.
• Due to the auger system, water consumption is equal to ice production.

Product Specifications

• Dimensions: 762mm (W) x 700mm (D) x 780mm (H)
• Weight Net: 146kg
• Packed Weight: 156kg
• Cooling: Air
• AC Supply Voltage: 1 PHASE 220-240V 50Hz / 15 AMP Plug
• Amperage: Running: 12.3A Starting: 76A
• Refrigerant Charge: R404A

Production Capacity per 24 hours

• Approx. 860kg @10°C Air temp; 10°C Water
• Approx. 730kg @ 21°C Air temp; 15°C Water
• Approx. 590kg @ 32°C Air temp; 21°C Water

Operating Conditions

• Ambient Temp.: 5-40°C
• Water Supply Temp.: 5-35°C
• Water Supply Pressure: 0.05-0.8MPa (0.5-8bar)
• Voltage Range: Rated Voltage ±10%

Max Storage Capacity

• 91000025 144kg Ice Storage Bin
• 91000026 217kg Ice Storage Bin
• 91000027 348kg Ice Storage Bin
• 91000053 578kg Ice Storage Bin

Additional Parts

• 87000123 Water Filter Kit Twin 450mm cartridges

• 87000107 450mm Replacement Cartridge
• 87000149 Water Filter System & Guage
• Sauermann External Drain Pump for Hoshizaki Ice Makers - NI82
• 81000116 Stainless Steel Hose
• 95001013 Adjustable Leg

Warranty

• 2 year parts & labour on entire unit
• 5 year (parts only) on compressor & air cooled condenser coil
• Get an additional 6 months when registering an Ice Machine

Product Resources

• Spec Sheet
