The Hoshizaki Modular Flake Ice Machine 500kg/day - FM-480AKE, the ultimate solution for businesses that require a large supply of high-quality flake ice. With its impressive output capacity of 500kg per day, this ice machine is perfect for busy commercial kitchens, fishing boats, and seafood markets.
The FM-480AKE is a modular ice machine, meaning it is designed to be used in combination with a separate ice storage bin or dispenser. This modular design allows for maximum flexibility in installation and allows you to customize your ice-making capacity according to your needs.
The machine is equipped with a high-quality stainless steel evaporator that produces flake ice that is perfect for a wide range of applications. Flake ice is known for its ability to cool beverages quickly while minimizing dilution, making it ideal for use in cocktails, smoothies, and other beverages.
The FM-480AKE features a user-friendly control panel that allows you to adjust the ice thickness and monitor the machine's performance. It also includes a hot gas defrost system that ensures reliable performance and reduces the need for manual cleaning.
In summary, the Hoshizaki Modular Flake Ice Machine 500kg/day - FM-480AKE is a reliable, efficient, and flexible ice machine that is perfect for businesses that require a large supply of high-quality flake ice. With its impressive output capacity, modular design, and user-friendly controls, this ice machine is sure to meet all of your ice-making needs.
Product Features
- “Freeze Burn” is no longer an issue when displaying fresh fish or produce.
- Carbon auger bearings have a longer life expectancy than roller bearing, reducing maintenance costs.
- Automatic flush function, helps keep the ice making system clean.
- Controller board with Operational Status display assists in troubleshooting.
- Due to the auger system, water consumption is equal to ice production.
- Can be converted to nugget ice by changing the extruding head and cutter (parts at an additional cost).
Product Specifications
- Dimensions: 560mm (W) x 700mm (D) x 780mm (H)
- Cooling: Air
- Weight Net: 95kg
- Packing Weight: 102kg
- AC Supply Voltage: 1 PHASE 230V 50Hz/ 10 AMP Plug
- Amperage Running: 8.4A Starting: 43A
- Refrigerant Charge: R404A
Production Capacity per 24 hours
- Approx. 500kg @10°C Air temp; 10°C Water
- Approx. 425kg @ 21°C Air temp; 15°C water
- Approx. 325kg @ 32°C Air temp; 21°C water
Operating Conditions
- Ambient Temp.: 5-40°C
- Water Supply Temp.: 5-35°C
- Water Supply Pressure: 0.07-0.8MPa (0.7-8bar)
- Voltage Range: Rated Voltage ±10%
Max Storage Capacity
Additional Parts
Warranty
- 2 year parts & labour on entire unit
- 5 year (parts only) on compressor & air cooled condenser coil
- Get an additional 6 months when registering an Ice Machine
